Cooperated with advanced 635nm red laser diode tech and a qualified glass coated lens inside a highly durable anodized aluminum alloy housing tube, not simply made into a simple red laser pointer, it is manufactured into a more professional cross line measuring tool of a 635nm red cross line laser module. It emits highly pure and bright red laser light source directly from an import 635nm red laser diode. Cooperated with basic thermal emitting system and constant electric power source supply, not relying on any prior cross line drawing or printing work, this accessory part of a 635nm red cross laser alignment always makes high speed, quick reaching and highly precise two perpendicular red lines generation at various work distances conveniently.
On consideration of high level of accuracy and highly bright cross line projection at different work distances, 635nm red cross line laser module enables freely selected output power. It applies an import 635nm red laser diode within 5mW to 100mW and high power up to 150mW to 500mW, cooperated with a metal heat sink cooling system inside a 16mm, 18.9mm and 26mm diameter anodized aluminum alloy housing tube, it gets sufficient space leaving for tube cooling down, and enables long term lasted two perpendicular red lines generation as long as 10 hours per day. Usually 635nm red cross laser alignment gets high visual brightness and a narrow line width. Only if it gets constant electric power source supply and makes constant red cross line projection within 8 to 10 hours per day, it provides precise cross line positioning and marking for industrial manufacturing, reducing processing errors.
Compared to traditional cross line positioning tools, such as rulers and stops, 635nm red cross line laser module enables even faster and longer time lasted measurement as expected. For example, in garment cutting, laser marking allows the cutter to quickly follow the line, improving work efficiency. When it applies a qualified glass coated lens with 10, 15 and 110 degree fan angles, it generates high linear quality and highly straight two perpendicular red lines generation with accurate 90 degrees and different dimensions. It is equipped with automatic constant current or automatic power control circuits, along with static electricity, surge, and reverse polarity protection. With a service life of 8,000 to 10,000 hours, it can operate stably in the complex environments of industrial production. Whenever it gets ultra compact size tube design,it can be easily installed on various industrial equipment without taking up too much space.
Applications in industrial manufacturing fields:
Assembly positioning: In automotive production lines, red cross lines can be projected to enable robots to accurately install parts such as doors, with mini
Quality Inspection Marking: When inspecting steel plate cuts, 635nm red cross line laser module is projecting cross lines on the metal plate quickly verifies whether the cut edge is perpendicular. When inspecting burrs on plastic parts, a red line is used to mark the edge of the product, making it easier to clearly see the burr under a magnifying glass.
Equipment Calibration: Red alignment laser is projecting cross lines on CNC machine tools can be used to calibrate the X/Y axes for absolute parallelism. On conveyor belts, crosshairs can be used to indicate belt deviation, facilitating timely adjustments. Special Processes: When engraving glass, a cross-shaped center point can be pre-marked on the craft glass to ensure the laser engraving does not deviate. For fabric cutting, a cross mark can be placed on piles of fabric, allowing the automatic cutter to follow the line and improve cutting accuracy.
Category: red cross line laser module
Multiple Application Field Used 635nm Red Cross Line Laser Module
Whatever kind of working surface users are in need of ultra clear and long time lasting cross line generation, in multiple industrial and high tech work fields, it would be an efficient job to operate a high energy density beam emitted tool of a 635nm red cross line laser module. It keeps work with low laser beam divergence and high linear quality red vertical and horizontal lines generation at long extending distance. Based on the use of correct output power and optic lens fan angle, and proper installation onto industrial device or equipment, not limited by long distance, high height and other complex working environments etc, this accessory part of a cross laser alignment tool brings users stable output power, long lasting cross line projection and long lifetime for all working occasions effectively.
Being made with durable anodized aluminum alloy housing tube, the real use of a 635nm red cross line laser module always bears wide range operating temperature of – 10℃ to 75℃, and storage temperature range of – 40℃ to 85℃. It can always adapt to a variety of different ambient temperature conditions and can also work stably in harsh industrial environments. Even though it applies an import semiconductor laser diode within 5mW to 100mW and 150mW to 500mW output power, however, after its proper design of a metal heat sink cooling system, this red cross laser alignment tool achieves superior nice heat dissipation, and increasing stability two perpendicular red lines generation as long as 10 hours per day.
Configured with different dimension tube for different output power range, the genuine use of a 635nm red cross line laser module is easily installed on various industrial equipment and instruments to provide positioning marking functions for different equipment. Under the same output power, the visual brightness of 635nm red laser is 3 times that of 650nm, and the long distance indication effect is better. It can also be clearly seen at a long work distance, which is suitable for long-distance cross line positioning and use in harsh lighting environments. This glass coated lens made cross laser alignment tool maintains good collimation, low light divergence and high straightness red cross line projection at different work distances. It can provide accurate cross line markings so as to ensure the accuracy of positioning.
Owing to its high stability cross line projection, long serving lifetime and easy integration with industrial device or equipment, this 635nm red cross line laser module can get ideal cross line alignment results for a lot of working occasions as below:
Clothing and textile industry: pure light and straight red cross line laser source can be used for clothing button point light source positioning, cloth cutting machine cloth cutting auxiliary marking, clothing folding laser marking positioning, etc., to help workers perform cutting, sewing and other operations more accurately, and improve the accuracy and efficiency of clothing production.
Woodworking and stone industry: It is suitable for marking and positioning of woodworking machinery such as single-piece longitudinal sawing machines, multi-piece longitudinal sawing machines, etc. Pro red cross laser alignment tool can also be used for stone cutting machines, stone bridge cutting machines, etc., to help operators accurately cut wood and stone, and improve processing accuracy and efficiency.
Tire production industry: It can be installed on radial tire forming machines and bias tire forming machines for positioning during tire production, which can effectively improve tire quality and play a role in quality assurance, increased production, and reduced consumption.
Electronic manufacturing industry: It can be used for electronic SMT positioning and framing, printed circuit board marking and positioning, etc., to help accurately place electronic components, ensure the accuracy of processes such as circuit board welding, and improve the production quality of electronic products.
Building decoration industry: It can be used for positioning in equipment installation and building decoration, such as wall tile paving, door and window installation, etc., to help construction workers quickly find the correct position and ensure the flatness and verticality of the decoration construction.
Entertainment game field: red alignment laser can be used in real-life CS and other laser confrontation games to accurately locate the player’s shooting position and judge whether it hits or not, and give players timely feedback through vibration, sound effects, etc.
Medical field: Red light with a wavelength close to 633nm has a certain therapeutic effect and can be used in photon therapy devices to target inflammatory skin problems, destroy acne-related bacteria, and promote wound healing. Although it is not exactly 635nm, the principle of similar wavelengths is similar. The 635nm red cross line laser module also has potential application value in skin beauty, rehabilitation treatment, etc.
High Visibility Glass Coated Lens 650nm Red Cross Line Laser Module
When 650nm red laser light is getting high naked eye recognition under natural light, in order to get more practical use in those of industrial and high tech work fields, laser tech engineer has just developed a quite professional measuring tool of a 650nm red cross line laser module. Even though it is used under higher lighting industrial environments, it can still present highly clear and bright two perpendicular red lines generation with accurate 90 degrees, reducing visual errors. Cooperated with proper operating voltage electric power source supply, this accessory part of red cross laser enables quite easy installation or integration, quick reaching and highly precise red cross line generation onto multiple working surfaces conveniently.
Usually 650nm red cross line laser module gets constant electric power source supply from an AC/DC adapter, which enables constant red laser beam emission at several miles far away. In addition, equipped with APC, ACC driving circuit board design, it enables perfect temperature control and electric current supply control, maintains stable output power and wavelength in industrial environments, such as temperature fluctuations and vibrations, and is not easy to attenuate in long term use. For the most important of all, being made with an inner metal heat sink cooling system, this red cross laser alignment maintains superior nice heat dissipation and ultra long time lasting red cross line projection as long as 10 hours.
Besides the use of a qualified glass coated lens with 10, 15 and 110 degree fan angles, this 650nm red cross line laser module is also equipped with adjustable focus optic lens. It generates high transmittance and high energy density red laser beam, and converts into ultra fine and straight red cross line source in distance. After quite easy screw of adjustable focus optic lens, when highly powerful red laser light source is concentrated, it enables increasing accuracy and brightness cross line generation for all precise mechanical processing works. The width of red cross line and the accuracy of the intersection can reach the millimeter level, meeting the positioning requirements of precision processing scenarios, such as micro-assembly of electronic components.
General use of 650nm red cross line laser module in industrial production:
Machining positioning: It projects red cross-lines on lathes, milling machines and other equipment to assist in workpiece clamping and tool alignment, such as marking cutting paths during sheet metal cutting to reduce manual calibration errors.
PCB board manufacturing: Used for position marking of circuit board drilling and patch processes to ensure accurate component welding positions and improve production line automation efficiency.
Wood/stone processing: Project cross-lines in woodworking machinery (such as electric saws and engraving machines) to help operators quickly align materials and control cutting angles and sizes.
Assembly line calibration: In automated production lines, red alignment laser is used for position calibration of multi-station equipment to ensure accurate docking of workpiece transmission paths and processing modules.
Construction: Installed on tower cranes, elevators and other equipment to assist in vertical positioning during hoisting operations, or to mark horizontal/vertical reference lines on walls and floors.
650nm Red Cross Line Laser Module For Mechanical Processing
In those of mechanical processing work fields, on consideration of its high accuracy and high brightness cross line projection onto different working surfaces, it should be a quite efficient job to operate a high energy density beam emitted tool of a 650nm red cross line laser module. Usually it adopts an import 650nm red laser diode and a qualified optic lens with different an angles inside a highly durable metal housing tube. It is working well with high precision and high straightness red vertical and horizontal lines generation at long extending distances. Whenever this compact structure made laser device gets proper installation and integration to correct position, it just enables easy reaching, long lasting and high precision cross line measurement for all working occasions conveniently.
When 650nm red cross line laser module gets easy mounting onto industrial device or equipment, even though it is not easy to reach, however, it still gets superior advantages for the real cross line measuring works. It applies advanced 650nm red laser diode within wide range output power of 5mW to 100mW, and 150mW to 500mW, besides its basic use of a metal heat sink cooling system, it also makes good use of durable anodized aluminum alloy housing tube. It gets good heatdissipation performance and thermal conductivity. Even though red cross laser is used within wide operating temperature range, and other harsh working occasion of mechanical calibration and different humidity, it still maintains ultra stable red vertical and horizontal lines generation in long time use.
Insides its high mechanical strength housing tube, based on a qualified glass coated lens with 10, 15 and 110 degree fan angles, 650nm red cross line laser module is generating highly straight and fine two perpendicular red lines with accurate 90 degrees and different dimensions. When it is selected with correct output power and optic lens fan angle, after its easy integration with desired machine or device, it is able to get significant advantages in the application and processing fields, which can greatly improve efficient and precision.
Cutting processing: red cross line laser module makes clear red crosshairs marking of the cutting path for cutting metal, wood, glass and other materials. Operators can adjust the position of the cutting equipment in real time so as to ensure accurate cutting, avoid deviation, improve cutting quality and reduce material waste.
Welding processing: red cross line source locates the welding points to assist workers to determine the welding positions and quickly and ensure ultra fine welding points. During welding, it provides real time position reference for welding equipment to ensure accurate welding trajectories, ensuring welding quality, reduce problems such as false welding and leaking welding. It is widely used in scenes with high welding precision requirements such as automobile body welding.
Drilling processing: During drilling operations, the 650nm red cross line laser module accurately locates the drilling position to prevent the drill bit from offsetting, ensure the hole position accuracy, and avoid scrapping the workpiece due to hole position deviation. In the fields of machinery manufacturing, aerospace parts processing, etc., strict requirements for high-precision hole positions are required, and the cross laser alignment work plays a key role.
Engraving: When engraving patterns or text, the crosshairs projected by the 650nm red cross line laser module help determine the engraving area and starting position. The engraving equipment calibrates the coordinates based on the crosshairs to ensure that the engraved content is accurately positioned and proportioned. It is often used in handicraft engraving, mold processing, etc. to improve the precision and quality of engraved products.
Precise Measured Glass Lens 650nm Red Cross Line Laser Module
What is an easy job to make ultra clear and precise enough cross line projection at various work distances? It is far more enough than formal hand reaching, not able to rely on any manual labor force input, it just makes a better job for users to operate a high density beam emitting device of a 650nm red cross line laser module. It gets advanced use of an import laser diode and qualified optic lens, configured with different dimension metal housing tube design, this accessory part of a 650nm red laser alignment just enables quite easy reaching, good direction and highly precise red vertical and horizontal lines generation with accurate 90 degrees at long extending distance conveniently.
Owing to the use of an AC/DC adapter, the genuine use of a 650nm red cross line laser module just makes constant and quick response red laser beam and red cross line source emission from beam aperture. It applies an import 650nm red laser diode within 5mW to 100mW as its beam emitting source. After basic equipment with a metal heat sink cooling system, it always gets increasing laser beam stability and ultra long time lasting red cross line projection from beam aperture. Any time cross laser alignment tool makes proper mounting onto other machine or device, it ensures noncontact and no barrier vertical and horizontal lines emission in continuous use.
Employed by a qualified glass coated lens with different fan angles of 10, 15 and 110 degree, when it is pointing onto different working surfaces, this 650nm red cross line laser module projects different dimension two perpendicular red lines at long extending distance and multiple lighting occasions as well. According to the real operating distance and lighting occasion, after its correct selection of output power and optic lens fan angle, this red cross laser alignment tool is able to make high precision measurement for laser alignment for screen printing system, heat transfer machine, laser medical therapy, military targeting and scientific experiment work etc.
According to quite easy use of a laser alignment mounting bracket, within freely installed distance, this 650nm red cross line laser module is operating conveniently as an accessory part of other machine or device. It makes sure of long lasting and long distance precise cross line alignment work for all labs, institutes and colleges etc. Whenever this alignment laser enables freely adjusted laser beam focus and cross line projection, within the maximum work distance of 25 meters and formal lighting occasions, it brings users quite satisfied measuring results effectively. Further more, according to basic obeying of laser safety issue and proper wearing of laser safety goggles, it just brings users quite easy reaching and highly secured measurement for all application fields.
How to Make Constant Use of 5mW to 100mW Pro Red Cross Laser Alignment?
Have you ever tried to make ultra clear and fine cross line generation before? If not, you should just have a try of a pure light emitting tool of a pro red cross laser alignment. Employed by an import 635nm red laser diode and a qualified optic lens, it just assured high quality red laser light source emission, and ultra clear and fine red cross line source generation at long extending distance. On the basis of its external electric power source supply, after its proper mounting onto those of industrial machine or device, this 635nm red laser module always brings users quite easy reaching, long lasting and high precision red vertical and horizontal lines generation at long extending distances constantly.
The usual use of a pro red cross laser alignment is always working for a quite long time, for the most important of all, it should have to maintain its stable and reliable red cross line source generation onto different working surfaces. It is applying an import 635nm red laser diode within 5mW to 100mW as its beam emitting source. Besides the use of a metal heat sink cooling system, after getting basic cooperation with a durable anodized aluminum alloy housing tube, this cross line laser module is always working well with superior nice thermal emitting and thermal conductivity, and maintaining up to 85% laser beam stability in long lasting use.
Cooperating with a qualified glass coated lens, whatever kind of working surface it is pointing, this pro red cross laser alignment generates high transmittance and highly powerful red laser light source at several miles far away. In practical precise cross line measuring work, available with wide range output power of 5mW to 100mW, it is not simply used for close distance and inner room. The selection of a high power 635nm red laser module up to 50mW to 100mW also projects ultra clear and fine red cross line source as long as 25 meters and other high lighting working occasions as well.
Being made with APC, ACC driving circuit board design, after the use of correct output power, this pro red cross laser alignment is working well with constant output power and electric current supply. It achieves long serving lifetime of more than 8,000 hours, and long lasting cross line indication, which also gets no tube burning out or damage. Thus this alignment laser gets wider and wider applications for a lot of industrial machinery processing works. Every time users are aware of any powerful red laser radiation and potential thermal energy hurt to eyes, after proper wearing of laser safety goggles, it still brings users easy and secured use in all working occasions constantly.
Fine Measured High Power 650nm Red Cross Line Laser Module
When users are looking for an easy operating cross line aligning tool, not limited by long distance, high height and other complex working environments, it should be an easy job for users to apply a high power 650nm red cross line laser module. It is projecting intense and powerful red laser light directly from 650nm red laser diode. Employing the most qualified glass coated lens with different fan angles and special use of separate cooling system and electric power source, high power red laser alignment is being made into an industrial stabilized cross line measuring device. It is able to work with easy and highly clear cross line generation for all precise device manufacturing work fields.
According to the use of a separate metal heat sink cooling system, cooperated with durable aircraft used aluminum alloy housing tube, this high power 650nm red cross line laser module just gets even larger space for tube cooling down than formal low power red laser. In addition, either it is pointing under low temperature or high temperature, it is still keeping clear and visible enough red laser beam emission. Only if this compact size tube made high power red line laser makes proper installation onto other machine or device, it just makes extremely clear and no decay light line projection in continuous use.
Designing with the best quality glass coated lens with different fan angles of 10, 15 and 110 degrees, high power 650nm red cross line laser module is performing with high transmittance red laser light emission, and high linear quality red vertical and horizontal lines generation with accurate 90 degrees. It is projecting various red cross line lengths within 0.5 meter to 6 meters. After correct selection of glass lens degree and output power, unless it is pointing under sunlight, high power red cross laser makes the most satisfied cross line alignment at great distance and other formal lighting occasions etc.
According to the use of extending electric wires for both high power red cross line laser module and DC power supply, it just enables the maximum installed distance of 3 meters and convenient cross line generation onto multiple working surfaces. This industrial alignment laser enables quite easy screw of adjustable focus optics and immediate red laser light concentration, it just achieves extremely fine and straight red cross line source emission in distance. When users are paying special attention to thermal energy hurt to eyes and wearing correct 650nm wavelength preventing laser safety goggles, without any eye exposure to laser beam aperture, this high power red cross laser makes safe and easy measurement in all occasions perfectly.
