Cooperated with advanced 635nm red laser diode tech and a qualified glass coated lens inside a highly durable anodized aluminum alloy housing tube, not simply made into a simple red laser pointer, it is manufactured into a more professional cross line measuring tool of a 635nm red cross line laser module. It emits highly pure and bright red laser light source directly from an import 635nm red laser diode. Cooperated with basic thermal emitting system and constant electric power source supply, not relying on any prior cross line drawing or printing work, this accessory part of a 635nm red cross laser alignment always makes high speed, quick reaching and highly precise two perpendicular red lines generation at various work distances conveniently.
On consideration of high level of accuracy and highly bright cross line projection at different work distances, 635nm red cross line laser module enables freely selected output power. It applies an import 635nm red laser diode within 5mW to 100mW and high power up to 150mW to 500mW, cooperated with a metal heat sink cooling system inside a 16mm, 18.9mm and 26mm diameter anodized aluminum alloy housing tube, it gets sufficient space leaving for tube cooling down, and enables long term lasted two perpendicular red lines generation as long as 10 hours per day. Usually 635nm red cross laser alignment gets high visual brightness and a narrow line width. Only if it gets constant electric power source supply and makes constant red cross line projection within 8 to 10 hours per day, it provides precise cross line positioning and marking for industrial manufacturing, reducing processing errors.
Compared to traditional cross line positioning tools, such as rulers and stops, 635nm red cross line laser module enables even faster and longer time lasted measurement as expected. For example, in garment cutting, laser marking allows the cutter to quickly follow the line, improving work efficiency. When it applies a qualified glass coated lens with 10, 15 and 110 degree fan angles, it generates high linear quality and highly straight two perpendicular red lines generation with accurate 90 degrees and different dimensions. It is equipped with automatic constant current or automatic power control circuits, along with static electricity, surge, and reverse polarity protection. With a service life of 8,000 to 10,000 hours, it can operate stably in the complex environments of industrial production. Whenever it gets ultra compact size tube design,it can be easily installed on various industrial equipment without taking up too much space.
Applications in industrial manufacturing fields:
Assembly positioning: In automotive production lines, red cross lines can be projected to enable robots to accurately install parts such as doors, with mini
Quality Inspection Marking: When inspecting steel plate cuts, 635nm red cross line laser module is projecting cross lines on the metal plate quickly verifies whether the cut edge is perpendicular. When inspecting burrs on plastic parts, a red line is used to mark the edge of the product, making it easier to clearly see the burr under a magnifying glass.
Equipment Calibration: Red alignment laser is projecting cross lines on CNC machine tools can be used to calibrate the X/Y axes for absolute parallelism. On conveyor belts, crosshairs can be used to indicate belt deviation, facilitating timely adjustments. Special Processes: When engraving glass, a cross-shaped center point can be pre-marked on the craft glass to ensure the laser engraving does not deviate. For fabric cutting, a cross mark can be placed on piles of fabric, allowing the automatic cutter to follow the line and improve cutting accuracy.
Category: cross line laser module
How Can Glass Lens 405nm Violet Cross Line Laser Module Work In Industrial Manufacturing
Any time users are getting serious need of ultra fine and accurate cross line projection at longer distance than formal hand reaching, not relying on any prior cross line drawing or printing work, a lot of factory workers and engineers would prefer to operate a highly bright beam emitted tool of a 405nm violet cross line laser module. It applies an import 405nm violet laser diode and a qualified glass coated lens with different fan angles, configured with different dimension metal housing tube and constant electric power source supply, it is used as an accessory part and making user of good direction and highly precise two perpendicular violet lines generation at various work distances and multiple lighting occasions conveniently.
Usually 405nm violet cross line laser module gets constant electric power source from a 5V, 9V or 12V 1000mA AC/DC adapter, which gets no need to make battery change during the constant cross line projection works. Employed by an import 405nm violet laser diode within 50mW to 100mW and high power up to 150mW to 500mW, after its special use of a metal heat sink cooling system inside its durable anodized aluminum alloy housing tube, it gets superior nice heat dissipation and ultra high level of laser beam stability in continuous use. When violet cross laser alignment generates two perpendicular violet lines with accurate 90 degrees with high precision, it can meet the demands of high-precision machining and assembly in industrial manufacturing.
In various industrial environments, being made with a qualified glass coated lens with 10, 15 and 110 degree fan angles, this 405nm violet cross line laser module projects highly bright and high contrast violet laser light, ensuring clear visibility even in bright light, facilitating accurate identification and operation. Being made with APC, ACC driving circuit board, whatever output power it is selected, it can make highly stable violet cross line projection with low output power fluctuation and long serving lifetime of more than 10,000 hours. Powered the by an external DC power supply, this violet cross laser alignment offers strong anti-interference capabilities, effectively suppressing inrush current and electromagnetic interference, ensuring stable operation in complex industrial environments.
Applications in industrial manufacturing fields:
Cutting and Drilling Guidance: 405nm violet cross line laser module provides precise violet crosshair positioning references for equipment such as laser cutting machines and CNC drilling machines, helping operators or automated systems accurately determine the location and direction of cutting or drilling, ensuring machining accuracy.
Welding Path Calibration: During the welding process, clear violet vertical and horizontal lines are projected to mark the location and direction of welds, assisting welders or welding robots in precise welding operations and improving weld quality and consistency.
Mechanical Assembly Calibration: Used in the assembly of mechanical components, violet crosshairs are used to determine the parallelism, perpendicularity, and coaxiality between components, ensuring assembly accuracy and improving equipment performance and reliability.
3D Printing Layer Alignment: During the 3D printing process, this helps calibrate the position of printed layers, ensuring that each layer of printed material is accurately placed in its intended location, improving the accuracy and quality of 3D printing. Machine Tool Guideway Calibration: 405nm violet alignment laser serves as a reference light source for machine tool guideway calibration. By observing the relative position of the crosshairs and the guideway, the guideway’s straightness and levelness can be quickly and accurately adjusted, ensuring machine tool processing accuracy.
Low Energy Consumption 445nm Blue Crosshair Laser Module for Textile Printing
When the advanced 445nm blue laser diode tech and a qualified glass coated lens are configured with a different dimension metal housing tube, it is manufactured into a quite professional cross line measuring tool of a 445nm blue crosshair laser module. Owing to its unique use of cooling system and constant electric power source supply, being made with different dimension metal housing tube design for different output power range, this direct diode emission made cross laser alignment tool always enables quite heat dissipation, ultra stable and clear blue vertical and horizontal lines generation at different work distances constantly.
In practical textile printing and dyeing work, this 445nm blue crosshair laser module is mainly used for fabric positioning and pattern overprint calibration. Owing to the adoption of a qualified glass coated lens with 10, 15 and 110 degree fan angles and an import 445nm blue laser diode within 50mW to 100mW and high power up to 150mW to 500mW, it always enables highly powerful and intense blue laser light emission, and efficient conversion of increasing accuracy and brightness two perpendicular blue lines generation at longer distance and higher lighting occasions as well. By projecting highly visible blue cross lines, this blue cross laser alignment addresses the issues of fabric deformation and difficult alignment during multiple processes.
This 445nm blue crosshair laser module maintains exceptional visibility in both natural and bright sunlight in textile workshops, far superior to red lasers. Operators can clearly identify positioning lines without shielding. When it gets constant electric power source supply, even though textile fabrics (such as chemical fibers and silk) are highly reflective, however, blue laser light still gets even higher penetration and contrast, which can effectively prevent blurring caused by reflections, ensuring accurate blue cross line positioning. Within the lowest energy and power consumption, this blue cross laser alignment always generates less heat at typical positioning powers, which can be used directly against flammable fabrics such as cotton, linen, and silk without the risk of burns.
What is the general use of blue crosshair laser module in textile printing works?
Fabric Cutting Positioning: The laser module is mounted above the cutting machine, and the projected blue crosshairs precisely align with the markings or pattern edges on the fabric, ensuring consistent cut dimensions for stacked layers of fabric and eliminating manual alignment errors.
Printing Color Registration Calibration: In multi-color overprinting processes (such as roller printing and flat screen printing), the blue cross line laser module serve as a reference line to calibrate the position of the front and back color plates, ensuring precise overlap of patterns and eliminating blurry or misaligned patterns caused by “color misregistration.”
Fabric Conveyor Alignment: In the fabric conveyor section of the printing and dyeing line, crosshairs can be projected onto the sides of the conveyor belt or the edges of the fabric. Auxiliary sensors monitor fabric deviation in real time, allowing timely adjustments to the conveyor direction to ensure consistent fabric movement.
Apparel Fabric Printing and Dyeing: 445nm blue cross laser alignment is used for overprinting multi-color patterns on garments like shirts and dresses, such as stripes and florals, ensuring precise alignment of patterns to prevent misalignment after garment completion.
Home Textile Fabric Processing: Assists in aligning the warp and weft directions of fabrics during the cutting and printing of large-area home textiles like bed sheets and curtains, ensuring uniform dimensions and symmetrical patterns in the finished product.
Industrial Fabric Production: For industrial fabrics like filter fabrics and geotextiles, where holes must be printed or cut in specific locations, alignment laser crosshairs ensure precise positioning of functional areas, meeting industrial requirements.
What is The Multiple Use of Glass Coated Lens 515nm Green Cross Line Laser Module
In various type of industrial and high tech precise cross line measuring work fields, not able to rely on manual or mechanical cross line alignment tool, it should be a much better solution for engineers and professionals to operate a high energy density beam emitted tool of a 515nm green cross line laser module. It is working well with easy reaching, highly clear and fine two perpendicular green lines with accurate 90 degrees at long extending distances. Based on the use of correct output power and optic lens fan angle, and constant electric power source supply, not relying on any manual labor force input, this 515nm green laser module is able to provide ultra clear, fine and precise cross line indication for multiple raw material processing works conveniently.
The primary use of a 515nm green cross line laser module is a type of high visibility and high precision cross line measuring tool. It is approximately six times brighter than a typical red laser, providing a clearly visible crosshair both indoors and outdoors, making it easily identifiable even in bright light conditions. Usually it applies an import 515nm green laser diode within 5mW to 100mW and high power up to 150mW to 200mW as its beam emitting source. In those of long time lasted cross line alignment work, owing to its basic use of a metal heat sink cooling system and APC, ACC driving circuit board design, 515nm green cross laser alignment tool gets intelligent feedback control of electric current and output power supply, thus it enables high level of laser beam stability of up to 85% in continuous use, and long serving lifetime of more than 8,000 hours.
In order to meet various high precision cross line positioning and alignment requirement, this 515nm green cross line laser module is also equipped with adjustable focus optic lens in front of beam aperture. It projects a crosshair with precise straightness and verticality. After its easy screw of laser beam aperture part, after its immediate forest green laser light source concentration, it is converting into an increasing fineness and brightness two perpendicular green lines as long as 25 meters and other higher lighting occasions as well. Owing to its typical use of 16mm, 18.9mm and 26mm diameter metal housing tube design, this cross laser alignment tool allows easy installation in various equipment and instruments, minimizing space requirements.
Applications:
Construction: 515nm green cross line laser module can be used for horizontal and vertical positioning of walls and floors, helping construction workers more accurately perform tasks such as masonry, tile laying, and door and window installation, improving construction efficiency and quality.
Industrial Manufacturing: In machining and electronics manufacturing, it is used for equipment installation and commissioning, production line calibration, and component positioning and alignment, ensuring accuracy and consistency throughout the production process.
Laser Measurement: As a core component in measuring equipment such as laser rangefinders and self-leveling laser tools, it provides a clear crosshair reference, facilitating measurements of distance, angles, levelness, and other parameters.
Medical: 515nm green alignment laser can be used in laser medical technologies, such as surgical positioning and rehabilitation therapy, providing precise guidance for medical procedures.
Applications of 445nm Blue Crosshair Laser Module in Wood Processing
Whenever cross line projection work is processing for those of wood processing works, such as engraving, cutting, and positioning works etc, it would be a quite efficient job for users to operate a highly intense beam emitted tool of a 445nm blue crosshair laser module. The 445nm blue light has a short wavelength and a small beam divergence angle, enabling micron-level engraving accuracy. The sharp crosshair edges enable more detailed wood engraving patterns, straighter cut lines, and more precise positioning. Every time blue cross laser gets constant electric power source supply, after its proper installation or integration with industrial wood processing machine or device, it enables high precision, highly bright and fine two perpendicular blue lines generation with accurate 90 degrees at various work distances conveniently.
Owing to the special use of AC/D adapter, not spending extra time spending on battery change, this 445nm blue crosshair laser module gets no need to spend extra time on alkaline battery change. It applies an import 445nm blue laser diode within 50mW to 500mW as its beam emitting source. Owing to its shorter wavelength of 445nm, wood has a high absorption capacity for blue light, and 445nm blue lasers are effectively absorbed by wood. This generates sufficient heat in a short period of time, rapidly melting or vaporizing the wood, resulting in high processing efficiency. At the same power level, it can cut thicker wood than other wavelength lasers.
Being made with a qualified glass coated lens within 10, 15 and 110 degree fan angles and adjustable focus optic lens design inside a durable anodized aluminum alloy housing tube, this 445nm blue crosshair laser module always projects highly straight and fine two perpendicular blue lines with accurate 90 degrees and different dimensions. It generates different cross line lengths within 0.5 meter to 6 meters. When users are making easy screw of laser beam aperture part, after its immediate blue laser light concentration from beam aperture, this cross line laser module gets increasing accuracy and brightness blue cross line source at longer distance and higher lighting occasions immediately. The blue crosshairs remain clearly visible even on rough or textured wood surfaces, unaffected by the wood’s color and surface characteristics. This facilitates observation and alignment, and provides excellent visibility even in brightly lit environments, such as outdoors. The crosshair spot size and line width of some modules are adjustable, allowing for optimal marking dimensions tailored to varying wood processing requirements and adapting to diverse processing scenarios.
In practical precise cross line measuring works, this durable metal housing tube made 445nm blue crosshair laser module undergoes multiple reliability verifications and high-temperature, long-term aging tests. It also features superior heat dissipation design and protection circuitry, ensuring stable operation and a long service life in wood processing environments. After correct use of output power and optic lens fan angle, and proper installation onto wood processing devices, this blue alignment laser can be used for wood engraving, using software mapping, the blue alignment laser projects blue laser beam energy onto the surface of the wood workpiece, achieving precise and efficient ablation, engraving various patterns and text. In cutting, it provides precise cutting path guidance for wood cutting equipment, enabling it to cut wood within a certain thickness. For positioning, it can be used as a reference mark in applications such as wood splicing and furniture assembly, ensuring accurate positioning between wood components and improving processing accuracy and efficiency.
808nm Infrared Crosshair Laser Module For Industrial Alignment and Positioning
Whenever advanced 808nm infrared laser diode tech and a qualified glass coated lens with different fan angles are applied for industrial grade laser device production, it is manufacturing into a professional cross line measuring tool of a 808nm infrared crosshair laser module. It emits intense and powerful infrared laser light source directly from an import 808nm infrared laser diode. Compared with traditional tools such as tape measures and squares, infrared cross laser alignment tool does not need to touch the workpiece and can complete positioning within seconds. They are especially suitable for mass production scenarios, which can significantly reduce auxiliary working hours and improve overall production efficiency.
The usual use of a 808nm infrared cross line laser module applies a qualified glass coated lens and adjustable focus optic lens design. The linear quality and verticality errors of the laser cross lines are extremely small, usually up to 0.1mm per meter level, and are not effected by ambient light (not under direct strong light), avoiding subjective errors and wear errors of manual visual positioning or mechanical contact positioning, and the accuracy remains stable for long-term use. When infrared cross laser alignment applies durable anodized aluminum alloy housing tube, it can achieves industrial grade module standard, which has the ability to resist vibration and electromagnetic interference, and can work continuously and stably in industrial environments with dust, oil pollution, and temperature fluctuations. The infrared light characteristics enable them to be clearly displayed in dark workshop environments (visibility can be enhanced with infrared receiving equipment or fluorescent plates).
Although 808nm infrared crosshair laser module applies an import 808nm infrared laser diode within 5mW to 500mW as its beam emitting source, however, it still adopts quite compact size tube diameter of 16mm, 18.9mm and 26mm. It gets various installation methods, for instance, which can be fixed on equipment racks, robotic arms or mounting bracket etc. According to quite easy screw of beam aperture part, this infrared laser alignment enables highly intense and powerful infrared laser light source concentration, and efficient conversion into increasing accuracy infrared cross line projection at greater distance. After proper adjustment of cross line projecting direction and thickness, it can be adopted to different work pieces and equipment of different sizes. It is easy to operate and install, without professional training, and operators can use it through simple debugging.
In industrial alignment and positioning, the 808nm infrared cross line laser module provides accurate spatial positioning reference for various industrial processing, assembly, detection and other links by emitting clear and stable infrared cross reference lines. It gets a lot of helpful applications as below:
• Mechanical processing: In the clamping of work pieces on lathes, milling machines and other equipment, the infrared cross line can quickly align the center axis or processing reference surface of the work piece to ensure the position accuracy of operations such as cutting and drilling, and reduce the scrap rate caused by positioning deviation.
• Sheet metal and welding: When splicing sheet metal parts, the cross-line emitted from a infrared cross laser can intuitively mark the vertical or horizontal alignment line of the splicing edge to avoid the error of manual marking; during welding, the weld position can be accurately located to ensure the consistency of the welding trajectory.
• Stone/wood cutting: On stone, wood and other plate cutting equipment, the infrared alignment laser can pre-mark the starting point and direction of the cutting path. The operator does not need to measure repeatedly and can directly cut according to the line, which greatly improves the cutting efficiency and dimensional accuracy.
• Assembly line assembly: In assembly line assembly of electronic products, automotive parts, etc., the infrared cross line source can be used as alignment marks for component installation to ensure precise docking of components in vertical and horizontal directions, and improve assembly speed and consistency.
Multiple Application Field Used 635nm Red Cross Line Laser Module
Whatever kind of working surface users are in need of ultra clear and long time lasting cross line generation, in multiple industrial and high tech work fields, it would be an efficient job to operate a high energy density beam emitted tool of a 635nm red cross line laser module. It keeps work with low laser beam divergence and high linear quality red vertical and horizontal lines generation at long extending distance. Based on the use of correct output power and optic lens fan angle, and proper installation onto industrial device or equipment, not limited by long distance, high height and other complex working environments etc, this accessory part of a cross laser alignment tool brings users stable output power, long lasting cross line projection and long lifetime for all working occasions effectively.
Being made with durable anodized aluminum alloy housing tube, the real use of a 635nm red cross line laser module always bears wide range operating temperature of – 10℃ to 75℃, and storage temperature range of – 40℃ to 85℃. It can always adapt to a variety of different ambient temperature conditions and can also work stably in harsh industrial environments. Even though it applies an import semiconductor laser diode within 5mW to 100mW and 150mW to 500mW output power, however, after its proper design of a metal heat sink cooling system, this red cross laser alignment tool achieves superior nice heat dissipation, and increasing stability two perpendicular red lines generation as long as 10 hours per day.
Configured with different dimension tube for different output power range, the genuine use of a 635nm red cross line laser module is easily installed on various industrial equipment and instruments to provide positioning marking functions for different equipment. Under the same output power, the visual brightness of 635nm red laser is 3 times that of 650nm, and the long distance indication effect is better. It can also be clearly seen at a long work distance, which is suitable for long-distance cross line positioning and use in harsh lighting environments. This glass coated lens made cross laser alignment tool maintains good collimation, low light divergence and high straightness red cross line projection at different work distances. It can provide accurate cross line markings so as to ensure the accuracy of positioning.
Owing to its high stability cross line projection, long serving lifetime and easy integration with industrial device or equipment, this 635nm red cross line laser module can get ideal cross line alignment results for a lot of working occasions as below:
Clothing and textile industry: pure light and straight red cross line laser source can be used for clothing button point light source positioning, cloth cutting machine cloth cutting auxiliary marking, clothing folding laser marking positioning, etc., to help workers perform cutting, sewing and other operations more accurately, and improve the accuracy and efficiency of clothing production.
Woodworking and stone industry: It is suitable for marking and positioning of woodworking machinery such as single-piece longitudinal sawing machines, multi-piece longitudinal sawing machines, etc. Pro red cross laser alignment tool can also be used for stone cutting machines, stone bridge cutting machines, etc., to help operators accurately cut wood and stone, and improve processing accuracy and efficiency.
Tire production industry: It can be installed on radial tire forming machines and bias tire forming machines for positioning during tire production, which can effectively improve tire quality and play a role in quality assurance, increased production, and reduced consumption.
Electronic manufacturing industry: It can be used for electronic SMT positioning and framing, printed circuit board marking and positioning, etc., to help accurately place electronic components, ensure the accuracy of processes such as circuit board welding, and improve the production quality of electronic products.
Building decoration industry: It can be used for positioning in equipment installation and building decoration, such as wall tile paving, door and window installation, etc., to help construction workers quickly find the correct position and ensure the flatness and verticality of the decoration construction.
Entertainment game field: red alignment laser can be used in real-life CS and other laser confrontation games to accurately locate the player’s shooting position and judge whether it hits or not, and give players timely feedback through vibration, sound effects, etc.
Medical field: Red light with a wavelength close to 633nm has a certain therapeutic effect and can be used in photon therapy devices to target inflammatory skin problems, destroy acne-related bacteria, and promote wound healing. Although it is not exactly 635nm, the principle of similar wavelengths is similar. The 635nm red cross line laser module also has potential application value in skin beauty, rehabilitation treatment, etc.
High Beam Visibility Glass Lens 532nm Green Cross Line Laser Module
If cross line measurement work is processing at different work distances and multiple lighting occasion,not able to rely on prior cross line drawing or printing work, it would be a much better solution to operate a highly bright beam emitted tool of a 532nm green cross line laser module. It applies the most advanced 532nm green DPSS laser tech, which stands the middle part of a visible optical spectrum, which is able to work with the most visible and the brightest green laser light source at long extending distance. As a result, once this accessory part of a green cross laser makes proper installation and integration with industrial device or equipment, it is able to work with ultra fine, straight and bright two perpendicular green lines generation for all machinery processing works constantly.
In order to achieve high level of accuracy cross line projection, this 532nm green cross line laser module is integrated with a qualified glass coated lens inside a durable anodized aluminum alloy housing tube. When it generates high transmittance green laser light source, it also converts into high linear quality and highly straight green vertical and horizontal lines at several miles far away. In addition, when cross line alignment work is processing within wide range operating temperature, different humidity, and other harsh working environments, such as mechanical moving or calibration, this cross laser alignment tool still maintains ultra stable cross line generation for those of industrial working occasions. It is always making good job for maintaining no mistake during industrial processing and assembly.
Being made with 16mm, 18.9mm and 26mm diameter tube design, together with electric wires extension for both of 532nm green cross line laser module and DC power supply, it enables quite easy installation, and quick response green cross line projection onto multiple working surfaces. Owing to its noncontact green cross line source projection, the whole process of industrial manufacturing works leaves no track onto any processing raw materials, thus making good job for improving working efficiency and assuring product quality in continuous use.
General applications in industrial manufacturing fields:
Laser cutting processing. Green cross line laser module projects highly fine and straight green cross line source, which is used for metal, wood and PCB driving circuit board cutting equipment. Only after correct use of output power and optic lens fan angle, it ensures precise cutting, reduced mistake, and improving cutting quality and efficiency.
Equipment installation and calibration: highly fine and straight green cross line laser source can help workers make accurate installation of the equipment in the predetermined position, ensuring the accuracy and verticality of the equipment installation, reduce installation errors, and improve the operation stability and reliability of the equipment.
Owing to its unique use of APC, ACC driving circuit board design, whatever output power it is selected, this 532nm green cross line laser module keeps work with high brightness and high stability green cross line projection in long time use, and enables long serving lifetime in all machinery processing works. When it makes proper installation or integration with industrial equipment, after basic obeying of laser safety issue and wearing correct 532nm wavelength preventing laser safety glasses, this industrial alignment laser just makes sure of secured and no mistake measurement effectively.
Important Use of 445nm Blue Crosshair Laser Module in Scientific Research
Based on the use of an import 445nm blue laser diode tech, not simply made into a blue laser pointer, it is manufacturing into a more practically used device of a blue crosshair laser module. It applies a short wavelength of 445nm, which can meet the strict requirement of scientific research experiments on the wavelength stability of blue laser light sources and ensure the accuracy and repeatability of experimental results . Under operation with constant electric power source supply and convenient installation or integration with other industrial machine or device, this accessory part of a cross laser alignment tool brings scientific researchers quite precise cross line alignment and observation effectively.
The output laser spot from a 445nm blue crosshair laser module has good uniformity, and the blue cross lines are clear and sharp. Featured by an import 445nm semiconductor laser diode and a metal heat sink cooling system design inside a durable anodized aluminum alloy housing tube, it always gets superior nice thermal emitting and heat dissipation. When it is operating under wide range operating temperature, different humidity and other harsh working environments etc, this blue cross laser still gets no obvious blue laser beam intensity fluctuation or distortion, which is conducive to accurate observation and measurement by scientific researchers.
Based on the use of a qualified glass coated lens in front of laser beam aperture, cooperated with a glass window in front, the genuine operation of a 445nm blue crosshair laser module gets a narrow line width, which can provide pure monochromatic light and reduce the interference of spectral broadening on the experiment. It is suitable for scientific research applications with high requirements for spectral purity, such as high-resolution spectral analysis. According to the selection of different optic lens fan angles of 10, 15 and 110 degree, this blue cross laser alignment emits different dimension blue vertical and horizontal lines with accurate 90 degrees and different dimensions within 0.5 meter to 6 meters length in real use.
Without spending extra time on alkaline battery power source change, only after its proper connects with 5V, 9V, 12V 1000mA AC/DC adapter, this 445nm blue crosshair laser module accepts wide range electric current supply and makes constant blue laser beam emission from beam aperture. Owing to its selected output power of 50mW to 100mW and high power up to 150mW to 500mW, it enables highly clear and precise blue cross line generation within the longest work distance of 25 meters and multiple lighting occasions easily. Owing to its high speed modulation, this blue alignment laser can achieve high-speed modulation, and can quickly switch the laser switch state or adjust the laser intensity according to experimental requirements, which is convenient for time-resolved experimental research, such as fluorescence lifetime measurement.
Applications in scientific research field:
Optical experiments: In experiments such as interference and diffraction of light, blue cross line laser module provides a stable blue laser beam as a light source. Its bright and accurate blue cross line laser source can facilitate researchers to observe and analyze the propagation characteristics and interference and diffraction patterns of light.
Material research: It is used for microstructure analysis of materials, such as studying defects and crystal structures inside materials through laser scattering technology. The short wavelength of cross line laser module enables it to detect the microscopic details of materials more accurately. In material processing research, it can be used to accurately control the position and range of laser processing and study the processing effect of materials under different energy densities.
Biomedical research: In the fields of fluorescence imaging, cell biology, etc., 445nm blue alignment laser light can excite specific fluorescent dyes for marking and observing biological molecules, cell structures, etc. The cross-line laser module can provide precise positioning, which is convenient for observation and analysis of specific areas.
Precise Measured Glass Lens 650nm Red Cross Line Laser Module
What is an easy job to make ultra clear and precise enough cross line projection at various work distances? It is far more enough than formal hand reaching, not able to rely on any manual labor force input, it just makes a better job for users to operate a high density beam emitting device of a 650nm red cross line laser module. It gets advanced use of an import laser diode and qualified optic lens, configured with different dimension metal housing tube design, this accessory part of a 650nm red laser alignment just enables quite easy reaching, good direction and highly precise red vertical and horizontal lines generation with accurate 90 degrees at long extending distance conveniently.
Owing to the use of an AC/DC adapter, the genuine use of a 650nm red cross line laser module just makes constant and quick response red laser beam and red cross line source emission from beam aperture. It applies an import 650nm red laser diode within 5mW to 100mW as its beam emitting source. After basic equipment with a metal heat sink cooling system, it always gets increasing laser beam stability and ultra long time lasting red cross line projection from beam aperture. Any time cross laser alignment tool makes proper mounting onto other machine or device, it ensures noncontact and no barrier vertical and horizontal lines emission in continuous use.
Employed by a qualified glass coated lens with different fan angles of 10, 15 and 110 degree, when it is pointing onto different working surfaces, this 650nm red cross line laser module projects different dimension two perpendicular red lines at long extending distance and multiple lighting occasions as well. According to the real operating distance and lighting occasion, after its correct selection of output power and optic lens fan angle, this red cross laser alignment tool is able to make high precision measurement for laser alignment for screen printing system, heat transfer machine, laser medical therapy, military targeting and scientific experiment work etc.
According to quite easy use of a laser alignment mounting bracket, within freely installed distance, this 650nm red cross line laser module is operating conveniently as an accessory part of other machine or device. It makes sure of long lasting and long distance precise cross line alignment work for all labs, institutes and colleges etc. Whenever this alignment laser enables freely adjusted laser beam focus and cross line projection, within the maximum work distance of 25 meters and formal lighting occasions, it brings users quite satisfied measuring results effectively. Further more, according to basic obeying of laser safety issue and proper wearing of laser safety goggles, it just brings users quite easy reaching and highly secured measurement for all application fields.
